SCM Minimax SC4 Elite 2600mm Panel Saw

https://www.mgmmachinery.com.au/web/image/product.template/3077/image_1920?unique=11e9239

High technology at a competitive price in a thicknessing planer for demanding craftsmen and carpentries.

Solid cast iron saw unit with double trunnions and independently adjustable scoring unit. Same 1270 mm rip capacity and micro-adjustable rip fence as all other Minimax sliders. With 2600mm sliding table. SCM’s #1 selling sliding table saw.

A perfect cut result is guaranteed by the saw unit constituted by a mighty, cast-iron structure. Great workpiece stability during machining with the large squaring frame, dimensions 1100 x 650 mm. Customisation for every use with an anodised aluminium sliding table 2600 mm stroke.

The elite series has proven itself in Australian cabinet shops for many years. With features normally found on much more expensive machines, the MiniMax SC4E can be yours for a fraction of the cost. See for yourself why the SC4 Elite 2600mm machine stands in a class of its own.

$ 13,900.00 13900.0 AUD $ 13,900.00 Excluding Gst

$ 13,900.00 Excluding Gst

    This combination does not exist.

    Contact Us
    Brand: SCM

    ​

    Technical features
    Circular saw:
    – Cast iron worktable dimensions[mm]840 x 560
    – Blades tilting90° ÷ 45°
    – Max. saw blade Ø with scoring blade installed[mm]315
    – Max. saw blade projection from table at 90°/45°[mm]100/71
    – Squaring stroke (standard)[mm]2600
    – Cutting width on parallel fence (standard)[mm]1270
    Other technical features:
    – Single-phase motor (seperate scoring saw motor)  2,2kW (3hp) 50Hz – + Scoring Saw
    Or

    – Three-phase motor (seperate scoring saw motor)

    		  4kW (5.5hp) 50Hz – + Scoring Saw
    – exhaust outlet diameter on base[mm]120
    -exhaust outlet overhead gaurd[mm]80
    Dust consumption [Ø 120 + Ø 80][m³/h](1647)
    Weight 651 kg
    Dimensions 280 × 108 × 111 cm
